| System Information | |
| CPU | Multimedia SoC (System-on-Chip) |
| Flash/ RAM | 256 MB/ 384 MB |
| Camera Features | |
| Image sensor | 1/3 inch Progressive CMOS |
| Maximum Resolution | 1280 x 1024 (1.3MP) |
| Lens Type | Vari-focal, Remote Focus |
| Focal Length | f = 3 ~ 9 mm |
| Aperture | F1.2 ~ F2.3 |
| Auto-iris | P-iris |
| Field of View | 34° ~ 80° (horizontal), 27° ~ 62° (vertical), 44° ~ 101° (diagonal) |
| Shutter Time | 1/5 sec. to 1/10,000 sec. |
| WDR Technology | WDR Pro II |
| Day & Night | Removable IR-cut filter for day & night function. Smart IR Technology to avoid overexposure |
| Minimum Illumination | 0.07 Lux @ F1.2, 50 IRE ( Color ), 0.001 Lux @ F1.2, 50 IRE ( B/W ) |
| Pan / Tilt / Zoom | ePTZ: 48x digital zoom (4x on IE plug-in,12x built in) |
| IR Illuminators | Built-in IR illuminators, effective up to 30 meters IR LED x 4, with Smart IR Technology |
| On-board Storage | SD/SDHC/SDXC card slot |
| Video | |
| Compression | H.264, MJPEG |
| Maximum Frame Rate | In both compression modes: 30 fps @ 1280 x 1024 |
| Maximum Streams | 2 simultaneous streams |
| S/N Ratio | 64 dB |
| Dynamic Range | 140 dB |
| Video Streaming | Adjustable resolution, quality and bitrate |
| Image Settings | Time stamp, text overlay, flip & mirror. Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks, scheduled profile settings, 3D noise reduction, EIS, video rotation |
| Audio | |
| Audio Capability | Two-way audio (full duplex) |
| Compression | AAC, G.711, G.726 |
| Interface | External microphone input. Audio output |
| Network | |
| Users | Live viewing for up to 10 clients |
| Protocols | IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP |
| ONVIF | Supported |
| Interface | 10Base-T/100 BaseTX Ethernet (RJ-45) |
| Intelligent Video | |
| Video Motion Detection | Triple-window video motion detection |
| Alarm and Event | |
| Alarm Triggers | Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection |
| Alarm Events | Event notification using digital output, HTTP, SMTP, FTP and NAS server. File upload via HTTP, SMTP, FTP and NAS server |
| General | |
| Smart Focus System | Remote focus |
| Connectors | RJ-45 for Network/ PoE connection. Audio input/output. AV output. AC 24V power input. DC 12V power input. Digital input x 1. Digital output x 1 |
| LED Indicator | System power and status indicator |
| Power input | DC12V/AC24V, IEEE 802.3af PoE |
| Power consumption | DC Max. 30W (Heater on) 8W (Heater off). AC Max. 30W (Heater on) 8.8W (Heater off) PoE Max. 11W |
| Dimensions | Ø: 91mm x 221 mm |
| Weight | Net: 1,314g (Body only) |
| Casing | Weather-proof IP67-rated housing |
| Safety Certifications | CE, LVD, FCC Class A, VCCI, C-Tick, UL |
| System Requirements | |
| Operating System | Microsoft Windows 8/7/Vista/XP/2000 |
| Browser | Mozilla Firefox 7~10 (Streaming only) |
| Internet Explorer 7/8/9/10 | |
| Other Players | VLC: 1.1.11 or above |
| QuickTime: 7 or above | |
- Bảo hành: 12 tháng
